Alpine Dash HLS

A ready-prepared video transcoding pipeline to create DASH/ HLS compatible video files & playlists.

Recommended usage via Docker Docker Desktop & Docker Hub.

Simplified usage (run in shell/ terminal/ cmd)

Prerequisite: Docker needs to be installed and running.

docker pull majamee/alpine-dash-hls
docker run -v /absolute/path/to/video/:/video majamee/alpine-dash-hls name_of_my_video_file.ext

Please just replace in the command above the absolute path to your video file folder and the full file name of your video file to be converted. You can also use tags like majamee/alpine-dash-hls:edge (e.g. uses alpine's edge version as base).

There is also a parameter --transcode-only which you can append to the docker run command, in order to skip the html and image file output. Example:

docker pull majamee/alpine-dash-hls
docker run -v /absolute/path/to/video/:/video majamee/alpine-dash-hls name_of_my_video_file.ext --transcode-only

Examplary toolchain usage

(Based on work of squidpickles)

Just use Kitematic to open the shared folder, place your video file in there, replace "input.mkv" in the commands below by your input video file (without "") and execute the shell commands subsequent into the Docker container.

# [email protected]
ffmpeg -y -threads 0 -i "input.mkv" -an -c:v libx264 -x264opts 'keyint=24:min-keyint=24:no-scenecut' -profile:v high -level 4.0 -vf "scale=min'(1920,iw)':-4" -crf 22 -movflags faststart -write_tmcd 0 intermed_1080p.mp4
# [email protected]
ffmpeg -y -threads 0 -i "input.mkv" -an -c:v libx264 -x264opts 'keyint=24:min-keyint=24:no-scenecut' -profile:v high -level 4.0 -vf "scale=min'(1280,iw)':-4" -crf 22 -movflags faststart -write_tmcd 0 intermed_720p.mp4
# [email protected]
ffmpeg -y -threads 0 -i "input.mkv" -an -c:v libx264 -x264opts 'keyint=24:min-keyint=24:no-scenecut' -profile:v high -level 4.0 -vf "scale=min'(720,iw)':-4" -crf 22 -movflags faststart -write_tmcd 0 intermed_480p.mp4
# 128k AAC audio only
ffmpeg -y -threads 0 -i "input.mkv" -vn -c:a aac -b:a 128k audio_128k.m4a

# Create MPEG-DASH files (segments & mpd-playlist)
MP4Box -dash 2000 -rap -frag-rap -url-template -dash-profile onDemand -segment-name 'segment_$RepresentationID$' -out playlist.mpd intermed_1080p.mp4 intermed_720p.mp4 intermed_480p.mp4 audio_128k.m4a

# Create HLS playlists for each quality level
ffmpeg -y -threads 0 -i intermed_1080p.mp4 -i audio_128k.m4a -map 0:v:0 -map 1:a:0 -shortest -acodec copy -vcodec copy -hls_time 2 -hls_list_size 0 -hls_flags single_file segment_1.m3u8
ffmpeg -y -threads 0 -i intermed_720p.mp4 -i audio_128k.m4a -map 0:v:0 -map 1:a:0 -shortest -acodec copy -vcodec copy -hls_time 2 -hls_list_size 0 -hls_flags single_file segment_2.m3u8
ffmpeg -y -threads 0 -i intermed_480p.mp4 -i audio_128k.m4a -map 0:v:0 -map 1:a:0 -shortest -acodec copy -vcodec copy -hls_time 2 -hls_list_size 0 -hls_flags single_file segment_3.m3u8
ffmpeg -y -threads 0 -i audio_128k.m4a -acodec copy -vcodec copy -hls_time 2 -hls_list_size 0 -hls_flags single_file segment_4.m3u8

# Transform MPD-Master-Playlist to M3U8-Master-Playlist
xsltproc --stringparam run_id "segment" /app/mpd-to-m3u8/mpd_to_hls.xsl playlist.mpd > playlist.m3u8

I am glad to receive any improvement ideas about this "any video to DASH/ HLS" pipeline. Especially if someone has any input on integrating better Apple's support of fragemented mp4 (fmp4) files in this pipeline.

Suggestions welcome. :)

General hints for hosting the files (to test streaming)

  • Video and playlist files should be hosted best via HTTPS
  • DASH requires the .mpd playlist to be set as Content-Type: application/dash+xml
  • No specific streaming server is required, but your hosting should have progressive downloading enabled
  • If using a different domain name for the video files compared to the page where the player is hosted CORS headers need to be set

Tools to test the generated files for streaming

  • HLS (e.g. Safari on Mac OS X): https://videojs.github.io/videojs-contrib-hls/ (use the .m3u8 master-playlist)
  • DASH (e.g. Firefox/ Chrome): https://reference.dashif.org/dash.js/ (use the latest released version & the .mpd playlist)

Features

  • Supported devices: iOS (Chrome/ Firefox/ Safari), Android (Chrome/ Firefox), Mac (Chrome/ Firefox/ Safari), Windows (Chrome/ Firefox/ EDGE)
  • Creates DASH (VOD) compatible files (including Safari on Mac)
  • Creates HLS files for compatibility with Safari on iOS
  • Optimizes video files for web playback (moov atom)
  • Compresses videos using [email protected] (for best compatibility)
  • Compresses audio using [email protected] (for DASH as separate track to save data)
  • Creates automatically 3 quality levels (Full HD/ HD/ DVD quality)
  • Fragments video files in 2 second windows to allow dynamic quality switching based on available bandwidth
  • Creates master MPD-Playlist which connects everything (MPEG-DASH)
  • Creates master M3U8-Playlist for HLS
  • Creates all output files neatly stored in a sub-folder matching the video file name in the folder output next to the transcoded video file
  • Adds also HTML and .htaccess file including code ready for inclusion into the own website for playback next to all other created files
  • Generates and sets Poster image (from second 3 of the input video file)
  • Generates and includes video preview thumbnails (currently only natively supported by Fluid Player via WebVTT)
  • Video preview support thumbnail support added for Video.js via videojs-vtt-thumbnails
  • Included fallback player (fluid-player.html) is based on the great work of the devs at Fluid Player
  • Included second fallback player (plyr.html) is based on the great work of the devs at Plyr
  • Included third fallback player (videogular.html) is based on the great work of the devs at Videogular
  • Included player (index.html) is based on the great work of the guys at Video.js

Tip

For creating DASH/ HLS compatible files for multiple videos in a single run, please have a look at:

Demo

https://majamee.de/demos
